Description: Button style head sits on reverse of panel and allows tie to be secured forming a loop. Allows pipes or cable bundles to be fixed to a panel using a single hole.
Releasable until finally secured.
Min. Loop Tensile Strength: 22kg
| Material | Polyamide 6.6(PA66 HS) |
| Colour | Black |
| Flammability | UL94V-2 |
| Operating Temperature | -40℃ to 105℃ |
| 编 号 | L(长) | W(宽) | (最大)捆扎范围 | 拉 力 | 孔径(φ) | 机板厚度 | ||
| Item No. | Max. Bundle DIA. | Tensile Strength | Hole Dia. | Panel Thickness | ||||
| Inch | mm | (mm) | (mm) | LBS | KGS | mm | mm | |
| SY1-9-48160 | 6 1/4" | 160 | 4.8 | 35 | 50 | 22 | 6.5~7.0 | 0.6~1.5 |
